技术参数/Technical Characteristic |
|||
|
电缆结构/Cable Construction |
|||
|
内导体/Inner conductor |
0.54mm |
7strands silver plated copper |
|
|
绝缘/Insulation |
1.52mm |
Extruded PTFE |
|
|
外导体/Outer conductor |
1.98mm |
Silver plated copper braiding |
|
|
护套/Jacket |
2.49mm |
PTFE tape wrapped, White |
|
|
|
|
|
|
|
电性能参数/Electrical Cable Characteristic |
|||
|
Capacitance |
96.5pF/m |
|
|
|
阻抗/Impedance |
50ohm |
|
|
|
速率/Velocity of Propagation |
69.5% |
|
|
|
工作频率/Operation frequency |
3.0GHz |
|
|
|
最大工作电压/Voltage Withstanding |
1200VRMS |
|
|
|
|
|
|
|
|
机械性能参数/Mechanical Cable Characteristic |
|||
|
最小弯曲半径(静态)/Inside Bend Radius (Minimum) |
12.7mm |
|
|
|
重量/Weight |
16.2g/m |
|
|
|
工作温度/Operating Temperature |
-65 up to +250℃ |
||
|
RoHS符合/RoHS Compliant |
是/Yes |
||
|
|
|
|
|
|
衰减/Cable Attenuation |
|||
|
频率/Frequency(GHz） |
|
衰减/Attenuation(dB/m) |
|
|
0.100 |
|
0.249 |
|
|
0.400 |
|
0.525 |
|
|
1.000 |
|
0.860 |
|
|
2.400 |
|
1.351 |
|
